Jabsco Diaphragm Bilge / Shower Drain Pump 12V 7A drain pump Marine J40-106 J40-106
$522.89 each
Brand: Jabsco Marine Pumps, Toilets & Spare Parts
The add to cart button will appear once you select the values above
Jabsco Diaphragm Bilge and Shower Drain Pump — 12V
Move water from a shower, sink drain or remote bilge pickup with this robust diaphragm pump.
About this product
The adjustable head and ports allow the drain hoses to be routed around the available space. Its joker-valve arrangement handles drainage without an inlet filter, reducing the number of components needing access for cleaning. Install the electrical protection and plumbing to the pump instructions.
Product details
- Single-chamber diaphragm design; corrosion-resistant components
- Mounting footprint matches the older Jabsco 37202 shower-drain pump
- Head rotates 360° and revolves at the motor joint; ports can be positioned at the required angle
- Delivery: 4.2 GPM / 16 litres per minute
- Self-priming lift: 3 metres
- Extended dry-running capability
- Quiet, ignition-protected motor
- Non-clogging joker valves; no inlet filter required
- Compact, simple service layout; low-maintenance design
- Dual-size inlet and outlet: 20mm (3/4 inch) or 25mm (1 inch) hose
- Dimensions: 254mm long × 156mm wide × 127mm high
- Electrical: 12V, 7A
- Jabsco model: 50880-1000
- Product code: J40-106
