Rule-A-Matic Plus 20A Marine Bilge Pump Float Switch with Debris Cover RWB98

$81.55 each
Brand: Rule Bilge Pumps, Float Switches & Parts

+
–
The add to cart button will appear once you select the values above

Rule-A-Matic Plus 20A Marine Bilge Pump Float Switch with Debris Cover

This Rule float switch provides water-level control for a compatible submersible bilge pump. It allows the pump to start and stop in response to rising and falling bilge water when the system is installed and wired correctly. Choosing the right switch involves checking the pump’s electrical demand as well as the space available around the float.

Choosing and using this product

Allow unobstructed movement around the float and position it in accordance with the manufacturer’s installation instructions. Loose cables, hoses or debris can interfere with operation, so the surrounding bilge area needs to remain clear. Ensure that the mounting location can be reached for inspection and testing without dismantling unrelated equipment.

Compare the stated switching limit with the pump’s requirements at the boat’s actual supply voltage. Similar-looking float switches are not necessarily interchangeable, and a higher-capacity pump may require a different control arrangement. Have a suitably qualified installer confirm the circuit protection, connections and any relay requirements rather than assuming that every pump can be connected directly.

After installation, test the complete system with water and check that the pump starts, discharges and stops as intended. Repeat functional checks as part of regular boat maintenance and after cleaning the bilge. Automatic switching is convenient, but it does not remove the need to inspect the boat or investigate persistent water entry. Keep the exact switch code with the vessel’s equipment records for future replacement.

When comparing replacement options, use the product code and the stated application together. Check the existing installation before ordering so that the selected component matches the equipment already on board.

Product details

  • Non-mercury, ignition-protected automatic float switch with sealed construction and moisture-blocked wiring.
  • No battery drain or exposed metal.
  • Integrated debris cover, 14-gauge abrasion-resistant blocked wiring and manual test feature.
  • Suits 12V, 24V and 32V submersible bilge pumps up to 20A.
  • Base footprint 135 x 63mm; height 72mm.
  • Product code: RWB98.
