AAA Blue Marine Underwater LED Light, 30W Polymer, 12V/24V, 235 Lumens RWB7813

$176.33 each
Brand: AAA Marine Inspection Ports & Boat Accessories

+
–
The add to cart button will appear once you select the values above

AAA Blue Marine Underwater LED Light, 30W Polymer, 12V/24V, 235 Lumens

This blue underwater light uses an encapsulated polymer body for a low-profile transom lighting installation. It is part of the AAA range of water-cooled marine lights, with a dedicated light-output figure for this colour rather than the higher rating of a different variant. Its surface-mounted format makes the housing size and cable-entry position important when planning a new installation or replacing an existing fitting.

Choosing and using this product

Water cooling is essential for this model, so do not use it as an above-water cockpit lamp or leave it illuminated while the boat is out of the water. Choose a position that stays submerged during intended operation and does not conflict with the outboard, trim tabs, boarding ladder or other fittings. Check access behind the proposed mounting area before committing to a location, including room for the cable and any supplied driver. The housing dimensions describe the light; they are not a drill template or a hull cut-out specification. Use the actual fitting and its installation instructions for marking and sealing. Keep cable joints protected from water and provide suitable circuit protection and switching for the installation. A competent marine installer should determine the fixing and sealing method for the hull construction. Once fitted, include the lamp, cable entry and fastenings in routine inspections, and assess the lighting effect under the water conditions in which the boat will normally be used.

Product details

  • Light colour: blue; catalogue light output: 235 lumens.
  • LED arrangement: 10 x 3W Samsung LEDs; 30W nominal LED total.
  • Suitable electrical systems: 12V and 24V.
  • Encapsulated, non-corrosive polymer construction; IP68 waterproof rating.
  • Overall light dimensions: 161mm x 76mm.
  • Supplied with 1.5m wiring, rubber wiring grommet and gland, and stainless steel fastening screws.
  • Catalogue LED life rating: 50,000 hours.
  • Water-cooled light: underwater operation is required.
