Manta Marine Bait Station Spare Flush-Mount Deck Socket for Folding Legs SP580

Manta Marine Bait Station Spare Flush-Mount Deck Socket for Folding Legs

The Manta SP580 is the individual replacement flush-mount socket for the stepped folding legs on the RWB1971 large and RWB1991 small bait stations. It is useful when renewing a damaged or missing mounting socket while keeping the matching station. The socket fits into the boat rather than sitting entirely above the mounting surface, so below-deck clearance is an essential part of selection. Both compatible stations use a pair of sockets, but this spare is sold individually, allowing the quantity to match the actual repair.

Choosing and using this product

Compare the old socket with the replacement before making any changes to the deck. Check the flange, fastening pattern and opening dimensions on the physical part, because the catalogue does not publish those measurements. For an existing installation, inspect the surrounding surface and old fastener holes for damage or water entry. Replace or repair unsuitable mounting material before fitting the socket. If installing two sockets, align them carefully so both stepped legs can enter without forcing the station or twisting its frame. Keep the stated 300mm centre spacing in mind, but use the actual station to verify the layout before drilling.

Use fixings, bedding and any backing required for the particular deck construction, with professional installation advice where needed. After fitting, check that the bait station seats fully and can be removed without binding. During routine cleaning, rinse the socket and clear trapped sand, bait residue and salt. Inspect its attachment and the mating legs before use, especially after a hard knock. If one socket is being replaced, also examine the other socket: uneven seating can indicate another installation issue. This part belongs to the folding-station socket system and should be matched by model rather than assumed to fit other Manta modular leg kits.

Product details

• Product code: SP580
• Application: RWB1971 and RWB1991 folding socket-mount bait stations
• Socket material: stainless steel
• Socket depth below mounting surface: 96mm
• Station installation spacing: 300mm between socket centres
• Quantity supplied: one socket
