T Bolt Hose Clamp - 74-79mm
Match the outside diameter of your assembled hose connection with this 74-79mm T-bolt clamp. Product 380181 is supplied in a box of 10.
Rolled band edges, solid trunnions and a 12 mm hex bolt form the heavy-duty fastening arrangement. This design is intended for fuel-fill and exhaust hose applications.
Use the 74-79mm range to check fit over the hose and its fitting. The hose internal diameter alone does not give the assembled outside diameter needed to choose a clamp.
The materials differ by component: the band and bridge are stainless steel, while the bolt is hardened steel and the trunnion is zinc-plated. Select by this complete construction rather than treating the whole clamp as stainless steel.
Choosing and using this product
For this version, size Range: 74-79mm. Use that specific detail when comparing the item with your existing equipment or planned installation. Other sizes and configurations in the range should be checked separately rather than treated as equivalent.
Keep service points accessible and follow the relevant system instructions for fastening, sealing and hose support. Avoid forcing a hose or thread to compensate for an unsuitable fitting. Confirm the finished connection and normal system operation before putting the installation back into use.
For a replacement, inspect the existing fitting and adjoining hose before ordering. Consider the direction of the connection as well as its size. An elbow, straight fitting or barbed tail changes the route and clearance needed even when the nominal connection size is similar.
Plan the connection from the system outward: identify the fluid application, mating thread or hose size, and the space available for the fitting. A nominal pipe-thread size is a separate measurement from a hose diameter, so compare the correct dimension at each connection.
Product details
- Size Range: 74-79mm
- Box Qty: 10
- Band/bridge: AISI 304/430 stainless steel
- Bolt: 12 mm hardened steel
- Trunnion: AISI 1035, zinc-plated with clear chromate finish
- Product code: 380181
