4 Gang Switch Panel
Create a coordinated control surface with this 4-gang stainless steel push-button panel. Part 709660 uses a brushed 316-grade stainless faceplate measuring 52 x 130mm, with blue LED on/off buttons arranged as a complete panel.
The 4 switch positions give you a defined circuit count to plan around. Compare both the overall faceplate dimensions and the smaller cut-out dimensions with the proposed console opening. The panel can be mounted horizontally or vertically, letting you choose the orientation that suits the available space.
The removable switches are pre-wired and rated at 15A for 12–24V operation. Each has a female non-terminated plug supplied, together with fuse holders. The non-terminated connections allow the panel to be incorporated into the boat’s wiring arrangement, with the final circuit design matched to the connected equipment.
The brushed surface provides a consistent metallic finish around the blue controls. A set of 100 icon labels is included so that each position can be identified by its actual function. Choose the labels after deciding which circuits will be assigned to the panel.
The buttons use standard maintained on/off actuation. Check that this operating action suits each intended circuit; a momentary function requires the appropriate switch arrangement. Allow access behind the panel for the connectors and wiring when assessing installation space.
The supplied mounting screws complete the listed fixing hardware. Check the cut-out carefully before cutting the mounting surface, and use the exact part code when selecting matching replacement components.
Blue illumination provides a consistent visual style across all of the panel’s push-button controls.
Product details
- Product: 4 Gang Switch Panel
- Product code: 709660
- Brushed 316 stainless steel switch panel with pre-wired removable blue LED on/off push buttons, 15A 12-24V rating, O-ring seal, female non-terminated plugs and fuse holders
- Horizontal or vertical mounting
- Includes 6 screws and 100 icon labels
- Dimensions: 52 x 130mm
- Cut Out Dimensions: 25 x 105mm
