2 Pin Waterproof Connector - 3amp
Use a screw-apart marine electrical connection with this 2-pin waterproof plug-and-socket set. Part 220120 is rated at 12V 3A.
The 2-pin arrangement identifies this version. A chrome-plated brass body, base seal, retainer chain and socket cover form the listed assembly. Different-sized contact holes help prevent reverse-polarity mating.
Match the contact arrangement and rating to the equipment wiring before installation. The socket cover and seal are part of the connection system and should be included when assessing the intended mounting location.
Choosing and using this product
For a panel-mounted item, check the cut-out and the clearance behind the panel as well as the visible dimensions. Terminals, cable bends and access for tools can require more room than the front of the component suggests. Confirm the mounting arrangement before altering the panel.
Keep circuit labels and the fitted product reference with the boat’s electrical records. This makes later fault-finding and replacement enquiries more straightforward. Before returning equipment to use, check the completed installation and its operation using the applicable instructions.
Choose the component for the actual circuit and power supply. Compare the stated voltage, current rating and switching or connection function with the equipment it will serve. A similar faceplate or connector shape does not establish the same electrical specification.
Check the exact supply format when ordering service parts. A replacement cover, boot, label, fuse or switch is distinct from a complete panel or assembly. Match the existing model and the stated part reference so that the item renews the intended component.
Plan the component together with the circuit wiring and protection. Follow the equipment instructions for the required connections and ratings, and keep the installation accessible for inspection. A component rating should not be treated as the rating of the entire assembled circuit.
Product details
- Product: 2 Pin Waterproof Connector - 3amp
- Product code: 220120
- Chrome-plated brass screw-apart waterproof plug/socket with base seal, retainer chain and socket cover
- Different-sized contact holes prevent reversed polarity
- 12V 3A
