150amp 12 Gang Buss Bar
Distribute a main DC supply to multiple connections with the 12-gang 150A bus bar, part 220170. It combines a tin-plated copper bar with an insulated ABS base.
The connection layout uses two 1/4-inch studs and ten 5/32-inch screws, giving this variant its specific terminal arrangement. The 152 x 32mm body includes two 5mm countersunk fastening holes.
Match the supply load, cable terminals and mounting footprint to the complete circuit design. The 150A rating is for the bus bar as a component and should be considered alongside the wiring and protection in the installation.
Choosing and using this product
Keep circuit labels and the fitted product reference with the boat’s electrical records. This makes later fault-finding and replacement enquiries more straightforward. Before returning equipment to use, check the completed installation and its operation using the applicable instructions.
For this version, size: 152 x 32mm. Use that specific detail when comparing the item with your existing equipment or planned installation. Other sizes and configurations in the range should be checked separately rather than treated as equivalent.
Check the exact supply format when ordering service parts. A replacement cover, boot, label, fuse or switch is distinct from a complete panel or assembly. Match the existing model and the stated part reference so that the item renews the intended component.
Choose the component for the actual circuit and power supply. Compare the stated voltage, current rating and switching or connection function with the equipment it will serve. A similar faceplate or connector shape does not establish the same electrical specification.
For a panel-mounted item, check the cut-out and the clearance behind the panel as well as the visible dimensions. Terminals, cable bends and access for tools can require more room than the front of the component suggests. Confirm the mounting arrangement before altering the panel.
Product details
- Product: 150amp 12 Gang Buss Bar
- Product code: 220170
- 150A tin-plated copper bus bar with insulated ABS base, 2 x 1/4-inch studs and 10 x 5/32-inch screws
- Size: 152 x 32mm
- Two 5mm countersunk fastening holes
