Switch Panel - 5 Gang with USB Charging Port
Build a compact control area with the Easterner 5-gang switch panel, part 702120. Its moulded black body measures 107 x 96mm and incorporates a USB charging port.
The USB charging port is integrated into this 5-gang version, bringing the accessory connection and switching into one panel footprint. Select it by the actual functions needed at the mounting location.
Fuses and labels are included. Reinforced corners help resist cracking around the screw holes, and gaskets provide a watertight seal at the mounting area. The panel is described as weatherproof.
The panels can be positioned above and below one another or side by side to create a larger bank. Plan the combined footprint and rear wiring space if you intend to use more than one panel.
Choosing and using this product
Keep circuit labels and the fitted product reference with the boat’s electrical records. This makes later fault-finding and replacement enquiries more straightforward. Before returning equipment to use, check the completed installation and its operation using the applicable instructions.
Plan the component together with the circuit wiring and protection. Follow the equipment instructions for the required connections and ratings, and keep the installation accessible for inspection. A component rating should not be treated as the rating of the entire assembled circuit.
Check the exact supply format when ordering service parts. A replacement cover, boot, label, fuse or switch is distinct from a complete panel or assembly. Match the existing model and the stated part reference so that the item renews the intended component.
For a panel-mounted item, check the cut-out and the clearance behind the panel as well as the visible dimensions. Terminals, cable bends and access for tools can require more room than the front of the component suggests. Confirm the mounting arrangement before altering the panel.
Product details
- Product: Switch Panel - 5 Gang with USB Charging Port
- Product code: 702120
- Easterner moulded black weatherproof switch panel with fuses and labels
- Reinforced corners and watertight gaskets
- Panels can be stacked vertically or horizontally
- Panel size: 107 x 96mm
