Johnson L1000 GPH Bilge Pump - 24v
Choose the 24v L1000 GPH Bilge Pump for a marine bilge installation that matches its hose size, capacity and electrical requirements. Product 184111 uses a 3/4” connection; the detailed flow figures below let you compare the pump at the stated test conditions.
Flow reduces as pumping head increases. Compare the zero-head figure with the rated output at the listed lift rather than treating the model name as the delivered flow at every installation. The test voltage is also relevant when comparing pump capacities.
The compact motor and impeller cartridge can be serviced without tools. A water-cooled motor and cartridge format make access for routine maintenance a practical part of the design.
This cartridge series meets ISO 8849 for marine bilge pumps. Keep the pump accessible so the motor/impeller unit can be removed for maintenance without treating the surrounding plumbing as permanent access space.
Both straight and 90-degree smooth-elbow Dura-Port discharge fittings are included, together with a removable check valve. Choose the outlet direction that suits the hose route while retaining access for cleaning.
Check the 24v supply, specified fuse and current draw together when selecting the electrical arrangement. Match the discharge hose to the 3/4” connection and leave room to service the pump after it is fitted.
For comparison, capacity Zero Head(13.6v/27v): 63Lpm - 1000GPH, while capacity at 3ft (0.9m) Head (13.6v/27v): 50Lpm - 800GPH. These two operating points show why the hose route and lift need to be considered with the capacity. Use the rated point relevant to the installation when narrowing the pump choice.
Replacement motor cartridges are offered separately within the Johnson range. Match the cartridge capacity and voltage to this pump when planning servicing; a 12 V service cartridge must not be selected merely because a 24 V pump has a similar housing.
Product details
- Voltage: 24v
- Capacity at 3ft (0.9m) Head (13.6v/27v): 50Lpm - 800GPH
- Capacity Zero Head(13.6v/27v): 63Lpm - 1000GPH
- Amperage: 2A
- Fuse Size: 3A
- Hose Size: 3/4”
- Base: 70 mm
- Height: 112 mm
- Standard: ISO 8849 marine
- Product code: 184111
