Johnson F7B-8 H/D Impeller Pump
Match your marine pumping application to the F7B-8 H/D Impeller. Product 10-24572-01 uses the mechanical drive and connection dimensions below.
The compact bronze pump is raw-water resistant and self-priming. Supported applications include marine-engine cooling water, bilge pumping, deck washing and fresh-water movement. Select the impeller and complete installation for the actual liquid and duty.
Compare the connection size, drive arrangement and body dimensions together. A pump with a similar appearance can have a different shaft size, mounting layout or weight, so use the exact model reference when replacing an existing unit.
Check both the available mounting space and the route into each port. Leave sufficient access to the pump head and service parts, and match the complete electrical or mechanical drive arrangement before installation.
The separate service-part references below identify replacement components for this pump. They are not additional loose inclusions supplied with the pump; use the exact references when planning a repair or routine service.
Choosing and using this product
A flow figure alone does not describe the complete installation. Hose routing, outlet height and the rest of the plumbing can affect the delivered result. Use the relevant pump guidance when sizing the system rather than treating a catalogue flow figure as a guaranteed output at every outlet.
For this version, length: 170mm. Use that specific detail when comparing the item with your existing equipment or planned installation. Other sizes and configurations in the range should be checked separately rather than treated as equivalent.
Product details
- Connection: 1” BSP
- Length: 170mm
- Width: 120mm
- Height: 50mm
- Weight: 1.9kg
- Drive Shaft: 5/8”
- Separate service part — Genuine impeller: 09-1028B
- Separate service part — Genuine nitrile impeller: 09-1028B-9
- Separate service part — Aftermarket impeller: 260406
- Separate service part — End plate: 01-46648-3
- Separate service part — End plate screws: 05-04-550
- Separate service part — Cam: 01-42679
- Product code: 10-24572-01
