Hydraulic Bracket Assembly
The hydraulic bracket assembly suits 3/4 inch, 7/8 inch and 1 inch master cylinders in the corresponding trailer brake arrangement. It provides the mounting assembly when that component needs replacement.
Compare the actual cylinder and bracket installation before ordering. A master cylinder is a separate component and is not stated as included.
Choosing and using this product
Keep the replacement part code and the trailer’s relevant dimensions together for later maintenance. Where more than one roller or running-gear size is fitted, label the location so subsequent orders can be matched to the correct position.
Review the supplied quantity and contents before planning the job. A component-only listing, pair and complete kit can cover different amounts of the repair. Matching or related product codes identify associated parts, but do not establish that those parts are included.
Identify the trailer assembly and the exact position being serviced before selecting a replacement. Hub, axle, coupling, spring and roller components each have their own dimensions and mating requirements. A similar overall appearance does not establish that two parts will fit the same trailer.
Measure the relevant mounting points and compare all stated dimensions. For rollers, check the bore and pin as well as the outside size. For running gear or mounting hardware, check the listed pattern and assembly details against the existing setup.
Before ordering a mounting component, check the space on both sides of the proposed location. The visible footprint, fixing access and clearance needed to remove the supported item are separate considerations. Compare those details with the existing installation so the component can be positioned usefully.
Use the trailer and component instructions for installation and inspection. Check adjoining parts for wear while the assembly is accessible, and confirm the finished arrangement before returning the trailer to use. A stated load rating is a capacity figure, not the weight of the component.
Product details
- Product code: 760269
- Hydraulic Bracket Assembly
- Suits 3/4 inch, 7/8 inch and 1 inch master cylinders.
