AXIS Seat Box Pedestal with Swivel Top
Build the seating position around the specified AXIS pedestal height and top configuration. An anodised aluminium post and base provide the pedestal structure, while the selected model determines whether a swivel, slide or separate top is required.
Use product code 648520 to identify this exact component when checking its fit with the existing assembly.
Measure from the supporting surface and include the seat and any additional hardware when checking the finished seating height. The pedestal height is only one part of that complete installation. Compare the base footprint with the available mounting area and check the seat connection before fitting.
These AXIS pedestals are specified for recreational use. Keep the posts at their supplied length: the pressed ends form part of the intended fit, so cutting is not an appropriate way to change height. Select the correct fixed height or adjustment range instead.
The swivel top provides 360-degree rotation and can connect directly to most compatible seats without an additional swivel. Check the actual mounting pattern, and keep the seat’s turning area clear around the pedestal.
Choosing and using this product
Inspect the deck support and fastening arrangement as part of the installation planning. Follow the relevant product and boat instructions, then include the attachment points and locking mechanisms in routine checks. Retain the model reference when compatible spare components may be needed later.
Match the connection at each end independently. The deck base must suit the mounting location, while the top must accept the intended seat or table fitting. A common-looking post diameter does not establish compatibility between every removable or locking system.
Allow space for any swivel, slide or release movement and check access to the adjustment controls. Nearby lockers, steering controls and walkways can influence the most useful position. Offer the complete arrangement into place before making permanent changes.
Product details
- 4-inch fixed-height anodised aluminium pedestal with 9-inch base.
- 360-degree swivel top mounts directly to most seats.
- Designed for seat boxes.
- Do not cut posts: ends are pressed for a tight fit.
- For recreational use only.
