AXIS 3 Bow Bimini 1.5 1.7m Boat Width 0.85m High Navy
Plan a shaded area aboard your boat with the navy AXIS 3 Bow Bimini, code 170801. This flat-pack boat canopy combines a 1500mm coverage length with a 1.5–1.7m mounting-width range and a 0.85m frame height, giving you three clear measurements to check before choosing your top.
With a 1500mm covered length and 0.85m height, this is the lower three-bow configuration. Check the vertical space above the proposed mounting position carefully, especially when comparing it with the taller 1.3m versions.
The navy fabric creates a dark blue canopy finish, complemented by black trim around the top. The canopy is made from 100% polyester, and the curved frame uses polished 1-inch aluminium tubing. The flat-pack design is intended for straightforward assembly, with instructions supplied to guide the process.
For width, measure between the actual mounting points and compare the result with the 1.5–1.7m range. The boat’s maximum hull width alone does not establish the correct fit. The main mounting position is approximately beneath the centre of the canopy, so its location affects where the covered area falls.
Measure height vertically from the mounting point when checking the 0.85m frame dimension. This is not a measurement from the boat floor. The bimini height can be trimmed by up to 0.2m; work through the supplied instructions and your chosen mounting arrangement before altering the frame.
Rear support arms, a bimini storage sock and side mounts are included. AXIS specifies a maximum of 40 knots, approximately 75km/h, with the top fully open. Use the supplied assembly and fitting instructions when setting up the canopy and its supports.
Product details
- Model: AXIS 3 Bow Bimini 170801.
- Mounting-width range: 1.5–1.7m.
- Height above mounting point: 0.85m; trimming allowance up to 0.2m.
- Coverage length: 1500mm.
- Canopy: navy 100% polyester with black trim.
- Frame: polished 1-inch aluminium tubing.
- Includes rear support arms, storage sock, side mounts and assembly instructions.
- Fully open rating: 40 knots (approximately 75km/h).
