ARK Premium Swing-Up Jockey Wheel 8 Inch
Choose the ARK Premium Swing-Up Jockey Wheel - 8 Inch for a trailer support arrangement that matches its wheel, mounting style and 350kg stated load capacity. Compare these details with the existing trailer installation before selecting a replacement.
The eight-inch wheel combines a powder-coated Sunraysia-pattern steel rim, low-profile solid tyre and sealed ball bearings. Zinc plating protects the stated metal finish, while the fold-away handle provides the listed storage arrangement.
The U-bolt swivel mount has a handle designed for easy swivelling. Check the drawbar mounting position and the space needed to move the assembly between operating and stored positions.
The listed 250mm extension is the adjustment travel, not a complete minimum-to-maximum installation height. Check the required support position before fitting.
The 350kg capacity applies to the stated assembly. It is not the gross trailer weight and should not be transferred to an individual spare wheel or clamp. Confirm the load carried at the support point and the condition of the mounting arrangement.
Choosing and using this product
Review the supplied quantity and contents before planning the job. A component-only listing, pair and complete kit can cover different amounts of the repair. Matching or related product codes identify associated parts, but do not establish that those parts are included.
Keep the replacement part code and the trailer’s relevant dimensions together for later maintenance. Where more than one roller or running-gear size is fitted, label the location so subsequent orders can be matched to the correct position.
Identify the trailer assembly and the exact position being serviced before selecting a replacement. Hub, axle, coupling, spring and roller components each have their own dimensions and mating requirements. A similar overall appearance does not establish that two parts will fit the same trailer.
Product details
- Zinc-plated jockey wheel with U-bolt swivel mount and handle designed for easy swivelling.
- Powder-coated Sunraysia-pattern steel rim, low-profile solid tyre, sealed ball bearings and fold-away handle.
- Wheel size: 8 inches.
- Maximum load: 350kg.
- Extension: 250mm.
- Product code: 766126
